| Tempat asal: | BUATAN CHINA |
| Nama merek: | Infinity Machine |
| Sertifikasi: | CE, ISO |
| Model Number: | RS-8330A-4 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Harga: | Negotiable |
| Packaging Details: | Standard export wooden case with operation manual and video inside. |
| Delivery Time: | Shipped in 15 days after payment |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
| Test amount: | 4 sets | Test load: | 80gf~500gf or 200gf~1000gf (or specified) |
|---|---|---|---|
| Test speed: | 10~60 cycles/min | Air source: | ≥0.6MPa |
| Dimension: | W1150xD400xH570mm | Weight: | 110kg |
| Cahaya Tinggi: | keyboard key tester,force testing machine |
||
Pneumatic Keystroke Tester
Model: RS-8330A-4
Purpose:
Apply for keystoke ( buttons) life-time test for mobile phone, telephone, car entertainment devices, PDA, bluetooth/ earphone, Automobile TV remote controller, MP3/CD ,the other electronic products and so on.
Feature:
The modes of sorting and same time clicking test can shift, and can simulate the real clicking condition for the key-clicking;
Adopt Japan SMC precise pneumatic component, hitting-strength is adjustable and long lifespan.
Adopt Mitsubishi touch LCD and PLC program controller.
Can test four sets mobile phone or other devices in the same time, any directions of the grips is adjustable, can satisfy to test keystoke of different kinds of products.
Can satisfy the testing of backside and front side of mobile phone, with hitting strength calibrating device which can response the anti-clicking ability of keystoke.
Control panel:
From left side to right side:
Power switch: turn right, power on, turn left, power off.
Emergency stop key: press this key while in emergency, return while turning by clockwise
Mitsubishi touch LCD: for program setting and control.
Calibrator: for test the load value (clear the data before test)—press” ∧” to do unit switching (g,kg,lb,N..) ALL ZERO(clear all data), PEAK ZERO—clear the peak data.
Specification:
| Model | RS-8330A-4 |
| Test amount | 4set |
|
The number of testing hitting fingers |
5pcs hitting fingers per station, total 20pcs. |
| Test load | 80gf~500gf or 200gf~1000gf (or specified) |
| Test speed | 10~60cycles/min |
| Test cycle | 1~999,999cycles settable |
| Dimension (WxDxH) | W1150xD400xH570mm |
| Weight | 110kg |
| Air source | ≥0.6MPa |
| Power Supply | AC220 50Hz 3A or specified by user |
Picture:
